SMT-120V Veterinary Automated Biochemistry Analyzer
Easy Operation
1.Inject 100ul sample
No pre-treatment for sample. Only 100ul whole blood/serum/plasma required for one panel.
2.Insert reagent disc
No maintenance, no need for centrifugation and adding diluent. No liquid system and other consumables such as pumps and valves.
3.Read results after 12 minutes
Microfluidic technology, no cross contamination. Result reports will be printed automatically.
SMT-120V is a state-of-the-art full automatic biochemical analyzer for animal diagnosis. SMT-120V can test up to 35 parameters at one time with precision reference laboratory quality results. No professional operation skills are required. The analyzer contains built-in centrifuge, QR code, Intelligent Quality Control. Full automatic operation, no need to add diluent and centrifuge. The test results will be printed automatically after 12 minutes. Easy 3-step operations: injecting sample, inserting reagent disc and the results will be printed, helping veterinarians make decisions rapidly. Upgraded android system makes the SMT-120V more user-friendly. More durable aluminum alloy casing make the analyzer more portable and more convenient.
Technical Specification:
Sample Type
Anti-coagulation whole blood, serum, plasma
Sample Volume
90-120μL
Bar Code
QR Code
Testing time
12 minutes/sample
Testing Principle
Absorption spectroscopy transmission turbidimetry
Testing Method
End point, kinetic, fixed time, turbidmetry etc
Temperature
37℃±0.2℃
Absorbance
3-3.0Abs
Resolution
0.001Abs
Cross Contamination
0
QC & Calibrate
IQC Intelligent QC
Working Condition
Temperature:10-32℃ Humidity: ≤85%
Light Source
120v/20w, halogen tungsten lamp’s lifespan is over 2500 hours
Power supply
AC 100-240V, 50-60 Hz
Optical System
After the filter spectral, 8 wavelength synchronous detection: 340,405,450,505,546,600,630,850nm
Display
Android 6.5 inch 800*480, multi-point capacitive touch screen
Storage
MAX 500,000 results
Printer
Built-in thermal printer
Connectors
2 USB ports
Weight
4.2Kg, power adapter: 0.6kg
Dimensions
191mm*213mm*220mm
Medical Disposable Reagent Disc
The reagent discs of Seamaty contain integrated components of optical and mechanical functions, and cooperate with the instrument to participate in each stage of blood analysis.Built-in QR code is innovatively used to identify the batch number, expiration date. Support setting of zone code to protect customers’ profit.The reagent discs contain lyophilized reagent beads and diluent, individual channel, less cross contamination.The storage temperature is 2-8 ℃ with one year’s shelf life.
